Nominal Voltage
6.0 v
NominalCapacity
12 Ah, 12000 mAh
Max.Charging current
3.6 A
Max.Discharging current
180 A max
Dimension (LxWxH)
151mm (5.95") x 50mm (1.97") x 94mm (3.7") (TH-100mm (3.94") - include terminal (T1))
Weight
1.48kg (4.37lb)
Terminal
T1
Detail Data Sheet
Please download the specifications for Lead acid battery 6.0v 12 ah.
Application
Electronic Toy-Cars, Emergency Lights, Rechargeable Flashlights, UPS, Fans.
Emergency lights: Lithonia ELB-0610, Chloride 100-001-074, Chloride 100-001-136 or 100-001-137, Chloride 100-001-078, Dual-Lite 12-533 or 12-534, Dual-Lite 12-268, Dual-Lite 12-631, Dual-Lite 12-713, Dual-Lite 12-723 or 12-727, Dual-Lite 12-825, Exide Part # 6V10K (2 pcs), Mule Part # 6GC028L, Exide Part # Q-9, Exide Part # 6V10 , High Lites Part # 039-02 or 039-03, Holophane Part # 90835A, Hubbell Part # 6V10, Hubbell Part # IB6V, Hubbell Part # IB6V, Panasonic Part # LCR-6V10, Portalac Part # PE-10-6R, Portalac Part # PE-6V10, Portalac Part # PX-06120, Prescolite 12-800, Prescolite 12-825, Prescolite ERB-0610, Prescolite 12-268, Prescolite E81911000, Sure-Lites 26-50, Teledyne Big Beam Part # 118-0065, Teledyne Big Beam Part # S-610, Yuasa Part # NP-10-6
Smart tip
To recharge 6v 1.2 Ah SLA battery, use either Smart Charger (1.3 A) for 6V Lead Acid Battery or Smart Charger (3.0 A) for 6V & 12V Lead Acid Battery
|
|
|
|
|
|
|
|
